| Parameter | Specification |
|---|---|
| Supply voltage | DC 12V~30V |
| Capacity | < 5W |
| Beam space | 2.5mm |
| Accuracy |
1.25mm (cross scanning based on 2.5mm) 2.5mm |
| Beams | 32-544 beams (Other can be customized) |
| Detection width | 80-4000mm (standard) |
| Wave length | 940nm |
| Detection distance |
0-200mm (with protective tube & bracket) 0-1000mm (Remark: if any light reflection, please let us know in advance) |
| Output method |
Analog voltage: 0-5V, 0-10V Analog current: 4mA-20mA Communication: RS485 (Modbus RTU) |
| Anti-optical interference | 10000Lux (angle > 5°) |
| Communication |
Mode: RS485, RS232 Baud Rate: 9600, 19200, 38400, 57600, 115200 bps Protocol: Modbus-RTU Data mode: Active mode, passive mode |
| Sensing method | Thru-beam |
| Synchronization | Wire synchronization |
| Enclosure material | Aluminum alloy, PC tube |
| Enclosure rating | IP65 |
| Ambient operating temperature | -10~55℃ (without freezing) |
| Storage temperature | -30~70℃ (without freezing) |
| Ambient operating humidity | Max 85% (when temperature is 20℃) |
