| Parameter | Specification |
|---|---|
| Power supply | DC 10V ~ 30V |
| Capacity | < 5W |
| Beam space | 10mm, 20mm, 40mm |
| Resolution | 15mm, 25mm, 45mm |
| Beams |
10mm : 8, 12, 16……128 20mm : 4, 6, 8, 10……64 40mm : 4, 6, 8, 10……32 |
| Protective height | Protective height = (N-1) * beam space (N is beam quantity) |
| Wave length | 940nm |
| Response time | Response time = (N * 0.1ms) + 0.4ms (N is beam quantity) |
| Type of output (OSSD) |
PNP or NPN Load current ≤ 200mA, Residual voltage ≤ 1V (except for voltage drop caused by cable extension), Leakage current ≤ 1mA. |
| Protective circuit | Overvoltage protection, Power supply reverse polarity protection, Over current protection. |
| Sensing distance |
0.1~0.5m, 0.1~1m, 0.1~2.5m (Remark: if have light reflection, please let us know) |
| Anti-optical interference | 10000Lux (angle > 5°) |
| Sensing method | Thru-beam |
| Synchronization | Wire synchronization |
| Enclosure material | Aluminum alloy |
| Enclosure rating | IP54 |
| Housing cross-section | 28 * 13mm |
| Ambient operating temperature | -10 ~ 55℃ (without freezing) |
| Storage temperature | -30 ~ 70℃ (without freezing) |
| Ambient operating humidity | When temperature is 20℃, humidity max 85% |
