Measuring Light Curtain

Product Feature:

1. Wide voltage power supply: the operating voltage is DC12-30V.
2.Detection accuracy: the detection accuracy can reach 2.5mm at most.
3.Long sensing distance: 2.5mm spacing can reach more than 3m sensing distance, 5mm and 10mm spacing can reach more than 5m sensing distance.
4.Avariety of data output: light spot blocking beam, light spot status, edge shading position.
5.Standard protocol: Modbus-RTU communication protocol is adopted.
6.Visual display of operation status: adopt digital tube and indicator light to display curtain working status.
7. Small appearance size:32mm*30mm sectional dimension.

Parameter	Specification
Power supply	DC 12V-30V
Capacity	< 5W
Detection precision	2.5mm, 5mm, 10mm
Beam space (Beams)	2.5mm: 32, 64 … 640 5mm: 16, 24 … 640 10mm: 16, 24 … 400
Detection height	(N-1) * beam space (N is beams)
Wavelength	940nm
Response time	(N * 0.1ms) + 0.4ms (N is beams)
Output type	Switch quantity: NPN, PNP Analog quantity: 0-5V, 0-10V, 4-20mA
Communication method	Interface: RS485 Protocol: Modbus-RTU Baud rate: 9600, 19200, 38400, 57600, 115200 bps Data mode: Active mode / Passive mode
Sensing distance	2.5mm: 0.1~1m, 0.1~3m (Switch/Analog); 0.1~2m (Encoder PP) 5mm: 0.1~1m, 0.1~3m, 0.1~5m (Switch/Analog); 0.1~2m (Encoder PP) 10mm: 0.1~1m, 0.1~3m, 0.1~5m (Switch/Analog); 0.1~3m (Encoder PP)
Sensing method	Thru-beam
Synchronization	Wire synchronization
Enclosure material	Aluminum alloy
Enclosure rating	IP65
Sectional size	32 * 30mm
Vibration resistance	Frequency 10-55Hz, amplitude 0.35±0.05mm, 20 times each in X, Y and Z direction
Ambient operating temperature	-10°C ~ 55°C (no freezing)
Storage temperature	-30°C ~ 70°C (no freezing)
Ambient operating humidity	Max 85% (at 20°C)
