| Parameter | Cable Type (-40) | M8 Connector (-60C) | M12 Connector (-70C) |
|---|---|---|---|
| Model NO | EV-TSM0802WO-40 EV-TNM0804WO-40 |
EV-TSM0802WO-60C EV-TNM0804WO-60C |
EV-TSM0802WO-70C EV-TNM0804WO-70C |
| Model NC | EV-TSM0802WC-40 EV-TNM0804WC-40 |
EV-TSM0802WC-60C EV-TNM0804WC-60C |
EV-TSM0802WC-70C EV-TNM0804WC-70C |
| Outer diameter | M8 | ||
| Installation / Distance |
Flush: 2mm No flush: 4mm |
||
| Material | Stainless steel or nickel-plated copper | ||
| LED | YES | ||
| Voltage | 10-60VDC (Allowable ripple voltage <10%) | ||
| Output | N.O. or N.C. | ||
| Load current | 3 – 100mA | ||
| Electrical Properties |
Leakage Current: <0.8mA Pressure drop: ≤5.5V Overload current: >120mA Instant protection: 2kV, 1mS, 1kohm |
||
| Protection Circuits |
Polarity reverse protection short circuit: YES Short circuit protection: YES |
||
| Switching frequency | 2KHZ (Flush) / 1KHZ (No flush) | ||
| Performance |
Switch hysteresis: <15% (Sr) Temperature error value: ±10% Repeatability: <2% (Sr) |
||
| Operating temperature | -25°C ~ +70°C | ||
| Cable / Connection | Cable (2M) 2.8Φ 3×0.15 or 2.8Φ 4×0.15 |
Cable (2M) (M8 Connector) |
Cable (2M) (M12 Connector) |
| Weight | 40g | 15g | 22g |
